Monitorrs Security 4K IP Kamerový systém 4 kam. GD
Kód: 4384Súvisiaci tovar
Podrobný popis
Pre Vás vhodný pevný disk si môžete vybrať pomocou nasledovnej tabuľky
|
Bitrate H.265 |
Veľkosť pevného disku |
Čas nahrávania |
|
8 Mpix Standard
|
1 TB |
5,9 dní |
|
2 TB |
11,8 dní |
|
|
3 TB |
17,7 dní |
|
|
4 TB |
23,7 dní |
|
|
6 TB |
35,5 dní |
Každý z našich kamerových systémov obsahuje káble s dĺžkou 20 metrov. Ak to chcete zmeniť, stačí pri objednávke zapísať požadované veľkosti káblov. Všetky naše kamerové systémy je možné objednať bez káblov. Nová cena sa dá vypočítať pomocou nasledujúcej tabuľky:
|
Tip |
Miera |
Cena |
|
Hotový kábel |
20 metrov |
Set obsahuje |
|
Hotový kábel |
30 metrov |
2,00 € |
|
Hotový kábel |
50 metrov |
6,00 € |
|
Kábel na mieru |
Do 50 metrov |
+ 0,20 €/1 m |
|
Kábel na mieru |
Nad 50 metrov |
+ 0,50 €/1 m |
|
Bez kábla |
- 4 € x počet kamier |
|
Pre jednoduchšiu inštaláciu našich kamerových systémov sme pre vás pripravili video návody.
Obsah balenia:
1 x 16-kanálový rekordér H.265+ 4 x PoE (6196)
4 x IP kamery 8 Mpix (6192)
4 x UTP kábel 20 m
1 x USB 2.0 myš
1 x Uživatelský manuál
1 x Disk Podľa výberu
A to najlepšie na koniec. Náš kamerový systém obdržíte nastavený a nakonfigurovaný. Nepotrebujete doobjednávať ďalšiu službu, to znamená, že inštaláciu zvládnete aj vy.
| Package | |
| NVR | 1x 3604CDP |
| Camera | 4 x 30S800 |
| Cable | 4x 20m CAT5e Cable |
| Mouse | 1xUSB 2.0 Mouse |
| Hard Disk | No |
| Adaptor | DC52V/1.25A |
| Weight | 6.8kg/SET |
| Camera Model | LBH30S800 |
| Image Sensor | 1/2.5" SONY Starvis Back-illuminated CMOS Sensor |
| Resolution | 8MP |
| Effective Pixels | 3864(H)*2218(V) |
| Compression | H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG |
| TV System | PAL/NTSC |
| Electronic Shutter Time | Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec |
| Minimun Illumination | 0.01Lux |
| S/N Ratio | ≥52dB |
| Scanning System | Progressive |
| Video Output | Network |
| Reset Button | Optional |
| Lens | |
| Focus Length | 3.6mm |
| Focus Control | Fixed |
| Lens Type | Fixed |
| Pixels | 8MP |
| Night Vision | |
| Infrared LED | 42µ x 4PCS |
| Infrared Distance | 40M |
| IR Status | Auto Control |
| IR Power On | Auto Control |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Wireless | / |
| Protocol | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP |
| ONVIF | Support ONVIF 2.4 |
| P2P | YES, Support QR Code |
| POE | Yes, Support IEEE 802.3af |
| Video Delay | 0.3S (Within the Lan) |
| Main Stream 1 | 3840*2160 @20fps 3072*2048@30fps |
| Main Stream 2 | 2592*1944@30fps 2560*1920@30fps |
| Main Stream 3 | 2560*1440@30fps 1920*1080@30fps 1280*720@30fps |
| Sub Stream 1 | 720*480@20fps 720*480@30fps |
| Sub Stream 2 | / |
| Sub Stream 3 | / |
| Tri Stream | 352*288@20fps 352*288@30fps |
| IE Brower |
IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53), Mac Safari(lower than version 12) |
| Smart Phone | iPhone, iPad, Android, Android Pad |
| Camera Features | |
| Day/Night | Color/ B&W (IR-CUT ) |
| Image Config |
Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control) |
| Starlight | / |
| Corridor Pattern | Support |
| Defog Mode | Support |
| ROI | Support |
| BLC | Support |
| HDR | / |
| WDR | DWDR: 50dB |
| Motion Detection | Support |
| Privacy Masking | 3 Rectangular Zone |
| Recording Mode | NVR/CMS/Web |
| Language |
Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Nederlands,Czech, Vietnamese |
| Interface | |
| Audio | Optional |
| Alarm | / |
| SD Card Slot | Optional, Support Max 512GB |
| RS485 | / |
| General | |
| Housing | Metal , IP67 |
| Anti-cut Bracket | YES |
| IR Cut Filter | YES |
| Operation Temperature | -20℃ ~ +60℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%, 950mA |
| Dimension | 157(W) x 70(H) x 66(D)mm |
| Weight | 650g |
| Model | NVR3604CDP |
| System | |
| Main Processor | ARM Cortex A7 Processor |
| Operating System | Embedded LINUX |
| Video | |
| Input | 16CH (3840×2160, 2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc) |
| Output | 1 VGA, 1 HD |
| Audio | |
| Input | 1 Port RCA |
| Output | 1 Port RCA(Linear, 1kΩ) |
| Audio Bit Rate | 64kbps |
| Audio Compression standard | G711u, G711a, ADPCM_DVI4 |
| Alarm | |
| Sensor Input | 4 |
| Output | 1 |
| Motion Detection | 16 Channel, MD Zones: 396 (22 × 18) |
| Trigger Events | Recording, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Display | |
| HD Output1 |
Resolution:4K (3840 × 2160)/30Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| HD Output2 | / |
| VGA | Resolution:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Display Split | 16CHxD1/9CHxD1/8CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k |
| Digital Zoom | YES |
| OSD | Camera Title, Time, Recording, Motion Detection, Event Alarm |
| Recording | |
| Video Compression | H265/H264/H265+/H264+ |
| Resolution |
4k(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536), 1080P(1920×1080),960P(1280x960),720P(1280×720),D1 (720×576/720×480) |
| Record Rate |
PAL :4k@10×25fp,5MP@14×25fp,4MP@16x25fp,3MP@16×25fp,1080P@16×25fp, 960P@16×25fp,720P@16×25fp, D1@16×25fp 960P@16×30fp, 720P@16×30fp, D1@16×30fp |
| Record Mode | Manualimerotion Detectionmart Alarm |
| Playback & Backup | |
| Local Sync Playback |
1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps, |
| Decode Capability | 1CH 4K(3840×2160)@30fps |
| Remote Sync Playback | YES |
| Search Mode | ALL, Channel, Manual, Time, Date, Motion Detection,Event Alarm |
| Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Full Screen, Frame Play ,Frame Rewind, Digital Zoom |
| Backup Mode | USB Device/Network |
| Network | |
| Interface |
4 x RJ45 (10M/100M Adaptive Ethernet Interface)+ 1xRJ45 10M/100M/1000M Adaptive Ethernet Interface |
| Incoming Bandwidth | 100MB |
| Network Functions | TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p |
| Onvif Version | Support Onvif 2.8 |
| Web Browser | IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53) |
| CMS Software | Support Windows 7/ Windows 8/Windows 10/MAC OS |
| Cloud Support(P2P) | Yes |
| Smart Phone | iPhone, iPad, Android, Android Pad |
| POE |
4 x Independent 100Mbps POE Network Interfaces(Output PowerAT mode 30W, AF mode 15W per Interface), 45/78 line order, Total Power Output≧50W, Support Plug and Play, Support network cable extended mode Max. 250M |
| WIFI | / |
| Storage | |
| Interface Type | 1 SATA Hard Disk Interface (2.5"/3.5" SATA) |
| Capacity | Up to 8TB capacity |
| eSATA | / |
| General | |
| Language |
Traditional Chinese, Simplified Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Korean, Dutch, Greek, Vietnamese, Janpenes |
| USB Interface | 2 USB 2.0 Interfaces |
| RS485 | / |
| Power Supply | DC 52V/1250mA ≤10W (Without Hard Disk and POE) |
| Working Environment | -10~55℃/10~90% |
| Dimension(W×D×H) | 260*215*43(mm) |
| Weight | 2.0KG (without HDD) |
Dodatočné parametre
| Kategória: | 8 Mpx |
|---|---|
| Záruka: | 2 roky |
