Monitorrs Security 4K AHD Kamerový set so 4 kamerami

Kód: 4116

Novinka

Neohodnotené

Značka: Monitorrs Security

Monitorrs Security 4K AHD Kamerový set so 4 kamerami

€500 €416,67 bez DPH

Môžeme doručiť do: 25.4.2024

AHD kamerový systém so 4 IR kamerami 8 MPix 4096 x 2160 s vysokým rozlíšením a nočným videním až do 40 m a so 4-kanálovým zariadením DVR.

Bez pevného disku! Disk si môžete vybrať vyššie.
Kamery sú v kovovom, antivandal puzdre s nočným prisvietením až do 40 m.

2,8 mm objektív s uhlom záberu 95 °,
Záznamové zariadenie s procesorom HI3531D s linuxovým operačným systémom,
české menu,
Video výstup: 1 x VGA, 1 x HDMI, CVBS,
Režim nahrávania Auto, Manuál alebo nahrávanie pri detekcii pohybu,
Možnosť sledovania na telefóne, tablete alebo na počítači z celého sveta bez nutnosti statickej IP adresy,
4 x kábel 18 m (na požiadanie aj dlhšie),
zapojenie zvládne aj laik.

Detailné informácie

Popis
Hodnotenie

Podrobný popis

Najmodernejšia technológia dostupná aj v AHD

Najmodernejší kamerový systém s veľmi vysokým rozlíšením, vďaka ktorému vám neujde ani najmenší detail.

Rekordér je vybavený unikátnou funkciou vzdialeného prístupu cez internet, vďaka ktorej sa k nemu môžete odkiaľkoľvek na svete pripojiť a prezerať si zhotovené záznamy či online prenos z pripojených kamier.

H.265

Kamerový systém využíva kódovanie H.265, vďaka ktorému sa zdvojnásobí využitie pevného disku.

Kamery sú v kovovom, vodotesnom (IP 66) antivandal puzdre s nočným prísvitom až do 40 m.

Pre naše sety nie je potrebná žiadna ďalšia investícia a zapojenie zvládne aj laik.

Obsah balenia:
1 x 4-kanálový rekordér XVR H.265
4 x kamery 8 Mpix (4096x2160)

4 x Kábel BNC 18 m
1 x Adaptér DC12V /5A pre kamery
1 x Adaptér DC12V/3A pre rekordér
1 x USB 2.0 myš
1 x Uživatelský manuál

8 MP 4IN1 HD Bullet IR 40 m

• 1/1.8'' OmniVision CMOS sensor
• AHD/CVI/TVI/CVBS 4 IN 1
• 4 mm Fixed Lens
• IR Distance Max. 40 m
• IP66 Outdoor, OSD&UTC Support

Camera
Image Sensor	1/1.8'' OmniVision CMOS sensor
Image Resolution	8 MP
Effective Pixels	*8 M:38402160**
TV System	PAL/NTSC
Electronic Shutter	1/25s~1/50,000s , 1/30s~1/60,000s
S/N Ratio	≥50dB
Scanning System	Progressive Scan
Lens
Focus Length	4 mm
Focus Control	Fixed
Lens Type	Fixed
Pixels	8 M Pixels
Auto Iris Support	NO
Night Vision
Infrared LED	42µ x 4PCS
Infrared Distance	40 M
IR Status	Under 6 Lux by AGC(F2.0)
IR Power On	AGC Auto Control
Camera Features
Starlight	/
Day/Night	YES
OSD Menu Language	YES
White Balance	AUTO / MANUAL
Gain Control	AUTO
Noise Reduction	3DNR
Picture Adjustment	YES
WDR	YES
OSD Support	YES
UTC	YES
Dip Switch	/
General
Housing	Metal, IP66
Bracket	YES
Dual Voltage	NO
IR Cut Filter	YES
Heater	NO
Audio	/
Operation Temperature	-10℃ ~ +50℃ RH95% Max
Storage Temperature	-20℃ ~ +60℃ RH95% Max
Power Source	DC12V±10%, 600mA
Dimension	157(W) x 70(H) x 66(D)mm
Weight	650g

4-CH H.265 5IN1 XVR 8-M

• Support AHD/CVI/TVI/IP/Analog Camera Input
• Up to HD 4K and IP 4K Resolution Recording
• Support HD Output, VGA and CVBS Video Output
• Support Max. 4-CH HD or 16-CH IP Camera Input
• Support 2 SATA up to 16 TB Capacity

System
Main Processor	HI3531D
Operating System	Embedded LINUX
Video
Input	*Analog: 4(TVI/AHD: 8 MP; TVI/AHD: 5 MP; AHD/TVI/CVI: 4 MP; AHD/TVI: 3 MP; AHD/TVI/CVI: 1080P/720P; Analog: 960H) Analog+Network:2Analog+14network(Max 8MP) Network: 32network(Max 8 MP)(Total incoming bandwidth ≤80 M)*
Input	4-CH BNC
Signal Type	Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network
Output	1 HD,1 VGA
Audio
Input	4-Channel, RCA
Two-way Audio	NO
Output	1-Channel, RCA
Alarm
Sensor Input	NO
Output	NO
Motion Detection	4-Channel(max 16-Channel in pure network mode)
Trigger Events	Recording, Email, Screen tips, Buzzer, Push notifications(motion detection)
Email Alarm	Send Image to The Designated E-mail
PTZ
Interface	RS485
Protocol	Pelco-D, Pelco-P
Baud Rate	110~921600
Address	0~255
Display
VGA	Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz
HD Output	Resolution: 3840×2160/30Hz, 2560x1440/30Hz, 1920 × 1080P/60Hz, 1280 × 1024/60Hz
Display Split	36-Channel/25-Channel/16-Channel/9-Channel/8-Channel/4-Channel / 1-Channel
Privacy Masking	3 Rectangular Zones (Each camera)
OSD	Camera title, Time, Video loss, Alarm, Motion detection, Recording
Recording
Video Compression	H.265/H.265+/H.264/H.264+
Audio Compression	G711u
Resolution	8 MP (3840×2160), 5 MP (2592×1944),4 MP (2560×1440),3 MP (2048×1536), 1080 P (1920×1080), 720 P (1280×720), 960 H (P:960×576/N:960×480)
Video Quality	worst/worse/ordinary/well/best
Record Rate	*Analog: PAL: 4k(38402160 412fps),5 MP (2592×1944 420fps), 4 MP(2560×1440 425fps),3 MP (2048×1536 418fps); 1080 P (1920x1080 425fps), 720 P (1280×720 425fps), 960 H (960×576 425fps)* *NTSC:4k(38402160 412fps), 5 MP(2592×1944 420fps), 4 MP (2560×1440 430fps), 3 MP (2048×1536 418fps), 1080 P (1920x1080 430fps),* *720 P (1280×720 430fps), 960 H (960×480 430fps)* Pure IP(H.265): PAL:4k@22×25fps,5MP@32×25fps,4MP@32x25fps,3MP@32×25fps, 1080P@32×25fps,960P@32×25fps,720P@32×25fps,D1@32×25fps NTSC: 4k@22×30fps,5MP@32×30fps,4MP@32×30fps,3MP@32×30fps, 1080P@32×30fps, 960P@32×30fps, 720P@32×30fps, D1@32×30fps
Record Mode	Manualimerotion Detection
Playback & Backup
Decode Capability	3CH 4K@30fps
Sync Playback	Pure Analog: 4CH 4K@12fps, 4CH 5M@20fps, 4CH 4M@30fps, 4CH 3M@18fps, 4CH 1080p@30fps Mix Mode: 4CH 1080P@30fps, 4CH 3MP@18fps, 4CH 4M@30fps, 3-CH 5 MP@20fps, 2-CH 4K@30fps Pure IPC: 3CH 4K@30fps, 4CH 5M@30fps, 6CH 4M@30fps, 6CH 3M@30fps, 9CH 1080P@30fps, 9CH 960P@30fps, 9CH 720P@30fps
Remote Playback	4 Channel / 1 Channel
Search Mode	ALL, Channel, Manual, Time, Date, Motion Detection
Playback Functions	Play, Pause, Stop, Fast play, Rewind, Digital Zoom, Full screen
Smart Phone Playback	4 Channel
Backup Mode	USB Device(with fomat FAT 32 )/Network
Network
Interface	1 RJ45 10M/100M/1000M Adaptive Ethernet Interface
Network Functions	TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP
DDNS	Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES
Web Browser	Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE
CMS Software	IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
Extra Stream	D1/CIF(1~30fps)
Smart Phone	iPhone, ipad, Android ,Android pad
Hard Disk Driver
Interface Type	2 SATA Interface
Capacity	2 SATA Hard Disk (2.5"/3.5" SATA, Up to 16TB)
General
Language	Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Farisa, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek
UTC Control	YES
USB Interface	2 USB 2.0 Interfaces
Power consumption	DC 12V ≤6W (Without Hard Disk)
Working Environment	-10~55℃/10~90%
Dimension (W×D×H)	*31029546(mm)*
Weight	3.5 kg (Without HDD)

	Najmodernejšia technológia dostupná aj v AHD
	H.265 Kamerový systém využíva kódovanie H.265, vďaka ktorému sa zdvojnásobí využitie pevného disku.
	Kamery sú v kovovom, vodotesnom (IP 66) antivandal puzdre s nočným prísvitom až do 40 m.
	Pre naše sety nie je potrebná žiadna ďalšia investícia a zapojenie zvládne aj laik.

Obsah balenia:
1 x 4-kanálový rekordér XVR H.265
4 x kamery 8 Mpix (4096x2160)

4 x Kábel BNC 18 m
1 x Adaptér DC12V /5A pre kamery
1 x Adaptér DC12V/3A pre rekordér
1 x USB 2.0 myš
1 x Uživatelský manuál

8 MP 4IN1 HD Bullet IR 40 m

• 1/1.8'' OmniVision CMOS sensor
• AHD/CVI/TVI/CVBS 4 IN 1
• 4 mm Fixed Lens
• IR Distance Max. 40 m
• IP66 Outdoor, OSD&UTC Support

Camera
Image Sensor	1/1.8'' OmniVision CMOS sensor
Image Resolution	8 MP
Effective Pixels	*8 M:38402160**
TV System	PAL/NTSC
Electronic Shutter	1/25s~1/50,000s , 1/30s~1/60,000s
S/N Ratio	≥50dB
Scanning System	Progressive Scan
Lens
Focus Length	4 mm
Focus Control	Fixed
Lens Type	Fixed
Pixels	8 M Pixels
Auto Iris Support	NO
Night Vision
Infrared LED	42µ x 4PCS
Infrared Distance	40 M
IR Status	Under 6 Lux by AGC(F2.0)
IR Power On	AGC Auto Control
Camera Features
Starlight	/
Day/Night	YES
OSD Menu Language	YES
White Balance	AUTO / MANUAL
Gain Control	AUTO
Noise Reduction	3DNR
Picture Adjustment	YES
WDR	YES
OSD Support	YES
UTC	YES
Dip Switch	/
General
Housing	Metal, IP66
Bracket	YES
Dual Voltage	NO
IR Cut Filter	YES
Heater	NO
Audio	/
Operation Temperature	-10℃ ~ +50℃ RH95% Max
Storage Temperature	-20℃ ~ +60℃ RH95% Max
Power Source	DC12V±10%, 600mA
Dimension	157(W) x 70(H) x 66(D)mm
Weight	650g

4-CH H.265 5IN1 XVR 8-M

• Support AHD/CVI/TVI/IP/Analog Camera Input
• Up to HD 4K and IP 4K Resolution Recording
• Support HD Output, VGA and CVBS Video Output
• Support Max. 4-CH HD or 16-CH IP Camera Input
• Support 2 SATA up to 16 TB Capacity

System
Main Processor	HI3531D
Operating System	Embedded LINUX
Video
Input	*Analog: 4(TVI/AHD: 8 MP; TVI/AHD: 5 MP; AHD/TVI/CVI: 4 MP; AHD/TVI: 3 MP; AHD/TVI/CVI: 1080P/720P; Analog: 960H) Analog+Network:2Analog+14network(Max 8MP) Network: 32network(Max 8 MP)(Total incoming bandwidth ≤80 M)*
Input	4-CH BNC
Signal Type	Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network
Output	1 HD,1 VGA
Audio
Input	4-Channel, RCA
Two-way Audio	NO
Output	1-Channel, RCA
Alarm
Sensor Input	NO
Output	NO
Motion Detection	4-Channel(max 16-Channel in pure network mode)
Trigger Events	Recording, Email, Screen tips, Buzzer, Push notifications(motion detection)
Email Alarm	Send Image to The Designated E-mail
PTZ
Interface	RS485
Protocol	Pelco-D, Pelco-P
Baud Rate	110~921600
Address	0~255
Display
VGA	Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz
HD Output	Resolution: 3840×2160/30Hz, 2560x1440/30Hz, 1920 × 1080P/60Hz, 1280 × 1024/60Hz
Display Split	36-Channel/25-Channel/16-Channel/9-Channel/8-Channel/4-Channel / 1-Channel
Privacy Masking	3 Rectangular Zones (Each camera)
OSD	Camera title, Time, Video loss, Alarm, Motion detection, Recording
Recording
Video Compression	H.265/H.265+/H.264/H.264+
Audio Compression	G711u
Resolution	8 MP (3840×2160), 5 MP (2592×1944),4 MP (2560×1440),3 MP (2048×1536), 1080 P (1920×1080), 720 P (1280×720), 960 H (P:960×576/N:960×480)
Video Quality	worst/worse/ordinary/well/best
Record Rate	*Analog: PAL: 4k(38402160 412fps),5 MP (2592×1944 420fps), 4 MP(2560×1440 425fps),3 MP (2048×1536 418fps); 1080 P (1920x1080 425fps), 720 P (1280×720 425fps), 960 H (960×576 425fps)* *NTSC:4k(38402160 412fps), 5 MP(2592×1944 420fps), 4 MP (2560×1440 430fps), 3 MP (2048×1536 418fps), 1080 P (1920x1080 430fps),* *720 P (1280×720 430fps), 960 H (960×480 430fps)* Pure IP(H.265): PAL:4k@22×25fps,5MP@32×25fps,4MP@32x25fps,3MP@32×25fps, 1080P@32×25fps,960P@32×25fps,720P@32×25fps,D1@32×25fps NTSC: 4k@22×30fps,5MP@32×30fps,4MP@32×30fps,3MP@32×30fps, 1080P@32×30fps, 960P@32×30fps, 720P@32×30fps, D1@32×30fps
Record Mode	Manualimerotion Detection
Playback & Backup
Decode Capability	3CH 4K@30fps
Sync Playback	Pure Analog: 4CH 4K@12fps, 4CH 5M@20fps, 4CH 4M@30fps, 4CH 3M@18fps, 4CH 1080p@30fps Mix Mode: 4CH 1080P@30fps, 4CH 3MP@18fps, 4CH 4M@30fps, 3-CH 5 MP@20fps, 2-CH 4K@30fps Pure IPC: 3CH 4K@30fps, 4CH 5M@30fps, 6CH 4M@30fps, 6CH 3M@30fps, 9CH 1080P@30fps, 9CH 960P@30fps, 9CH 720P@30fps
Remote Playback	4 Channel / 1 Channel
Search Mode	ALL, Channel, Manual, Time, Date, Motion Detection
Playback Functions	Play, Pause, Stop, Fast play, Rewind, Digital Zoom, Full screen
Smart Phone Playback	4 Channel
Backup Mode	USB Device(with fomat FAT 32 )/Network
Network
Interface	1 RJ45 10M/100M/1000M Adaptive Ethernet Interface
Network Functions	TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP
DDNS	Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES
Web Browser	Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE
CMS Software	IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
Extra Stream	D1/CIF(1~30fps)
Smart Phone	iPhone, ipad, Android ,Android pad
Hard Disk Driver
Interface Type	2 SATA Interface
Capacity	2 SATA Hard Disk (2.5"/3.5" SATA, Up to 16TB)
General
Language	Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Farisa, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek
UTC Control	YES
USB Interface	2 USB 2.0 Interfaces
Power consumption	DC 12V ≤6W (Without Hard Disk)
Working Environment	-10~55℃/10~90%
Dimension (W×D×H)	*31029546(mm)*
Weight	3.5 kg (Without HDD)

Dodatočné parametre

Kategória:	KAMEROVÉ SYSTÉMY
Záruka:	2 roky
